Sedimentological study of phosphorite deposits based on “Phosphate Factory” model: a case study of the Ediacaran Doushantuo Formation phosphorites in central Guizhou Province,China

doi:10.7605/gdlxb.2025.091

Journal of Palaeogeography（Chinese Edition） ›› 2025, Vol. 27 ›› Issue (5): 1081-1103. doi: 10.7605/gdlxb.2025.091

• PALAEOGEOGRAPHY AND MINERAL RESOURCES • Next Articles

Sedimentological study of phosphorite deposits based on “Phosphate Factory” model: a case study of the Ediacaran Doushantuo Formation phosphorites in central Guizhou Province,China

DU Yuansheng¹(), GUO Hua¹, ZHANG Yaguan¹, LIU Jianzhong², WANG Zepeng³, WU Wenming³, CHEN Guoyong², ZHAO Zheng⁴, DENG Chao⁵

1 China University of Geosciences(Wuhan), Wuhan 430074, China
2 Bureau of Geology and Mineral Exploration Development of Guizhou Province, Guiyang 550004, China
3 Geological Brigade 105, Bureau of Geology and Mineral Exploration Development of Guizhou Province, Guiyang 550018, China
4 Geological Brigade 104, Bureau of Geology and Mineral Exploration Development of Guizhou Province, Guizhou Duyun 558000, China
5 Geological Brigade 115, Bureau of Geology and Mineral Exploration Development of Guizhou Province, Guizhou Qingzhen 551400, China

Received:2025-04-13 Revised:2025-05-30 Online:2025-10-01 Published:2025-09-30
About author:
DU Yuansheng,born in 1958,is a professor and Ph.D. supervisor of China University of Geosciences(Wuhan). He is mainly engaged in the researches of sedimentary geology. E-mail: duyuansheng126@126.com.
Supported by:
Ministry of Natural Resources-Guizhou Province Pilot Cooperation Project(2023ZRBSHZ060); Phosphate Ore Survey and Evaluation Project in Bijie Region,Guizhou Province

基于“磷酸盐工厂”的磷矿沉积学研究: 以黔中地区埃迪卡拉系陡山沱组磷矿为例^*

杜远生¹(), 郭华¹, 张亚冠¹, 刘建中², 王泽鹏³, 吴文明³, 陈国勇², 赵征⁴, 邓超⁵

1 中国地质大学(武汉), 湖北武汉 430074
2 贵州省地质矿产勘查开发局, 贵州贵阳 550004
3 贵州省地质矿产勘查开发局 105地质队, 贵州贵阳 550018
4 贵州省地质矿产勘查开发局 104地质大队, 贵州都匀 558000
5 贵州省地质矿产勘查开发局 115地质大队, 贵州清镇 551400

作者简介:
杜远生,男,1958年生,中国地质大学(武汉)教授,博士生导师,主要从事沉积地质学研究。E-mail: duyuansheng126@126.com。
基金资助:
*部省合作试点项目(2023ZRBSHZ060); 贵州省毕节地区磷矿调查评价项目联合资助

Abstract

Abstract:

The Ediacaran(Sinian) Doushantuo Formation in the central Guizhou Province represents a significant phosphorite metallogenic province hosting high-grade phosphate deposits in China. To elucidate the metallogenic geological conditions,deposit characteristics,and mineralization processes of the Doushantuo Formation phosphorites in the central Guizhou region, based on the principles of ore sedimentology and “Phosphate Factory”model,this study systematically investigates the phosphorite-bearing series through an integrated analysis of petrology,sedimentary facies and palaeogeography. Our research indicates that the primary phosphorites of the Doushantuo Formation in central Guizhou are dominated by intraclastic phosphorites(including sandy,gravelly,and silty intraclasts),with minor amounts of oolitic,peloidal,bioclastic,and stromatolitic phosphorites. The phosphorite ores are primarily characterized by phosphatic cement overgrowths and dolomitic cements in the pore,with subordinate clay matrix infillings. Secondary phosphorites include earthy to semi-earthy varieties,as well as brecciated and silicified phosphorites. Palaeogeographic studies reveal that the phosphorites mainly formed in an open beach environment along the northern and eastern margins of the central Guizhou Oldland,with localized development of stromatolitic phosphorites in tidal flat settings. The phosphorite horizons(Phosphorite-A and Phosphorite-B)are controlled by two transgressive-regressive cycles. The high-grade phosphorites in the Ediacaran(Sinian) Doushantuo Formation of central Guizhou underwent a three-stage mineralization process: initial phosphate precipitation,wave-winnowing concentration,and secondary leaching enrichment. Based on this framework,we propose an open-shoreline mineralization model for the Doushantuo phosphorites.

Key words: phosphorite, phosphate factory, ore sedimentology, Ediacaran(Sinian), Guizhou Province

摘要：

贵州黔中地区是中国埃迪卡拉(震旦)系陡山沱组富磷矿的重要矿集区,为了揭示黔中地区陡山沱组磷矿的成矿地质条件、矿床地质特征和成矿地质作用过程,以矿产沉积学的思想为主导,以“磷酸盐工厂”的理论为基础,通过含矿岩系的岩石学、沉积相和古地理等手段进行系统研究。研究表明,黔中地区陡山沱组原生磷矿以内碎屑(包括砂屑、砾屑、粉屑)磷矿为主,含少量鲕粒状磷矿、生物颗粒或球粒磷矿及叠层石磷矿。矿石填隙物包括胶结物和基质,其中胶结物为围绕磷质颗粒增生的磷灰石胶结物和孔隙内的白云石胶结物,基质为黏土质。次生磷矿包括渣土状、土状—半土状磷矿和碎裂及硅化磷块岩。古地理研究表明磷矿主要形成于黔中古陆北部、东部边缘的无障壁海滩沉积环境,局部发育磷质叠层石为特色的潮坪。磷矿层位(A矿层和B矿层)受2期海侵—海退旋回制约。黔中埃迪卡拉(震旦)纪陡山沱组富磷矿经历了初始成矿作用、波浪簸选富集成矿、淋滤富集成矿三阶段成矿过程,在此基础上建立了陡山沱组磷矿无障壁海滩的成矿模式。

关键词: 磷矿, 磷酸盐工厂, 矿产沉积学, 埃迪卡拉(震旦)纪, 贵州省

CLC Number:

P588.24+4

DU Yuansheng, GUO Hua, ZHANG Yaguan, LIU Jianzhong, WANG Zepeng, WU Wenming, CHEN Guoyong, ZHAO Zheng, DENG Chao. Sedimentological study of phosphorite deposits based on “Phosphate Factory” model: a case study of the Ediacaran Doushantuo Formation phosphorites in central Guizhou Province,China[J]. Journal of Palaeogeography（Chinese Edition）, 2025, 27(5): 1081-1103.

杜远生, 郭华, 张亚冠, 刘建中, 王泽鹏, 吴文明, 陈国勇, 赵征, 邓超. 基于“磷酸盐工厂”的磷矿沉积学研究: 以黔中地区埃迪卡拉系陡山沱组磷矿为例^*[J]. 古地理学报, 2025, 27(5): 1081-1103.

/ / Recommend / Download Citations

URL: http://www.gdlxb.cn/EN/10.7605/gdlxb.2025.091

http://www.gdlxb.cn/EN/Y2025/V27/I5/1081

Figures/Tables 17

References 61

[1]	陈其英. 1981. 磷块岩的内碎屑. 地质科学, 16(2): 153-158,199.
	[Chen Q Y. 1981. Study on the intraclast of phosphorite. Chinese Journal of Geology, 16(2): 153-158,199]
[2]	陈其英, 郭师曾. 1985. 中国东部震旦纪和寒武纪磷块岩的结构成因类型及其沉积相和环境. 地质科学, 20(3): 224-235,313-314.
	[Chen Q Y, Guo S Z. 1985. Texture-genetic types,facies characteristics and formation environment of phosphorites of Sinian and Cambrian in eastern China. Chinese Journal of Geology, 20(3): 224-235,313-314]
[3]	杜远生, 陈国勇, 张亚冠, 刘建中, 陈庆刚, 赵征. 2017. 贵州省震旦纪陡山沱组磷矿沉积地质学. 湖北武汉: 中国地质大学出版社.
	[Du Y S, Chen G Y, Zhang Y G, Liu J Z, Chen Q G, Zhao Z. 2017. Sedimentary Geology of the phosphorite deposits from the Sinian Doushantuo Formation in Guizhou Province. Wuhan: China University of Geosciences Press]
[4]	杜远生, 周琦, 余文超, 张亚冠, 王萍, 覃永军, 庞大卫. 2018. 贵州南华纪—震旦纪沉积大地构造及其对沉积矿产的控制作用. 贵州地质, 35(4): 282-290.
	[Du Y S, Zhou Q, Yu W C, Zhang Y G, Wang P, Qin Y J, Pang D W. 2018. Sedimentary geotectonics and its control function of sedimentary mineral in Nanhua Period-Sinian Period in Guizhou. Guizhou Geology, 35(4): 282-290]
[5]	杜远生, 余文超, 张亚冠. 2020. 矿产沉积学: 一个新的交叉学科方向. 古地理学报, 22(4): 601-619.
	[Du Y S, Yu W C, Zhang Y G. 2020. Ore sedimentology: a developing interdisciplinary research direction of sedimentology. Journal of Palaeogeography(Chinese Edition), 22(4): 601-619]
[6]	刘魁梧. 1985. 沉积磷块岩结构类型、成因及成矿阶段. 沉积学报. 3(1): 29-41,140-141.
	[Liu K W. 1985. The texture types,geneses and ore-forming stages of sedimentary phosphorite. Acta Sedimentologica Sinica, 3(1): 29-41,140-141]
[7]	密文天. 2010. 上扬子地区震旦纪陡山沱期成磷事件研究: 以贵州瓮安、湖北宜昌磷矿床为例. 成都理工大学博士学位论文.
	[Mi W T. 2010. Study on phosphorus formation in Doushantuo period of sinian in Upper Yangtze Region: taking Weng’an, Guizhou and Yichang,Hubei as examples. Doctoral dissertation of Chengdu University of Technology]
[8]	密文天, 林丽, 周玉华, 付修根, 马叶情. 2009. 贵州瓮安陡山沱组磷块岩生物标志物特征及对沉积环境的指示. 沉积与特提斯地质, 29(2): 55-59.
	[Mi W T, Lin L, Zhou Y H, Fu X G, Ma Y Q. 2009. Biomarkers of the phosphorites and their indicators of the sedimentary environments of the Doushantuo Formation in Weng’an,Guizhou. Sedimentary Geology and Tethyan Geology, 29(2): 55-59]
[9]	聂文明, 马东升, 潘家永, 周健, 吴凯. 2006. 黔中新元古代—早寒武世含磷岩系δ¹³C变化及其古海洋意义. 南京大学学报(自然科学版), 42(3): 257-268.
	[Nie W M, Ma D S, Pan J Y, Zhou J, Wu K. 2006. δ¹³C excursions of phosphorite-bearing rocks in Neoproterozoic-Early Cambrian interval in Guizhou,South China: implications for Paleoceanic evolutions. Journal of Nanjing University(Natural Sciences), 42(3): 257-268]
[10]	覃永军. 2015. 江南造山带西段新元古代下江群年代地层标定与盆地演化. 中国地质大学(武汉)博士学位论文.
	[Qin Y J. 2015. Chronostratigraphic calibration and basin evolution of Neoproterozoic Xiajiang Group in the western segment of Jiangnan orogenic belt. Doctoral dissertation of China University of Geosciences(Wuhan)]
[11]	王剑, 段太忠, 谢渊, 汪正江, 郝明, 刘伟. 2012. 扬子地块东南缘大地构造演化及其油气地质意义. 地质通报, 31(11): 1739-1749.
	[Wang J, Duan T Z, Xie Y, Wang Z J, Hao M, Liu W. 2012. The tectonic evolution and its oil and gas prospect of southeast margin of Yangtze Block. Geological Bulletin of China, 31(11): 1739-1749]
[12]	吴祥和, 韩至钧, 蔡继峰. 2000. 贵州磷块岩. 北京: 地质出版社
	[Wu X H, Han Z J, Cai J F. 2000. Phosphorite of Guizhou. Beijing: Geological Publishing House]
[13]	夏学惠, 东野脉兴, 陈代良. 2012. 黔中开阳地区磷块岩巨量堆积与陆缘坻控矿作用. 矿床地质, 31(S1): 1185-1186.
	[Xia X H, Dongye M X, Chen D L. 2012. Phosphate rock massive and continental margin up lift controls the mineralization of Kaiyang area in central Guizhou Province. Mineral Deposits, 31(S1): 1185-1186]
[14]	杨卫东, 曾允孚. 1990. 黔中陡山沱期磷块岩成因的系统研究. 沉积学报, 8(3): 84-92.
	[Yang W D, Zeng Y F. 1990. Systematic research on the origin of the phosphorites of Doushantuo stage central Guizhou,China. Acta Sedimentologica Sinica, 8(3): 84-92]
[15]	叶连俊, 陈其英, 赵东旭. 1989. 中国磷块岩. 北京: 科学出版社.
	[Ye L J, Chen Q Y, Zhao D X. 1989. Phosphorites in China. Beijing: Science Press]
[16]	张伟, 杨瑞东, 毛铁, 任海利, 高军波, 陈吉艳. 2015. 瓮安埃迪卡拉系灯影组叠层石磷块岩形成环境及成矿机制. 高校地质学报, 21(2): 186-195.
	[Zhang W, Yang R D, Mao T, Ren H L, Gao J B, Chen J Y. 2015. Sedimentary environment and mineralization mechanism of the stromatolitic phosphorite in the Ediacaran Dengying Formation,Weng’an County of Guizhou Province,China. Geological Journal of China Universities, 21(2): 186-195]
[17]	张亚冠, 杜远生, 陈国勇, 刘建中, 王泽鹏, 徐圆圆, 谭代卫, 李磊, 王大福, 吴文明. 2016. 黔中开阳地区震旦纪陡山沱期富磷矿沉积特征与成矿模式. 古地理学报, 18(4): 581-594.
	[Zhang Y G, Du Y S, Chen G Y, Liu J Z, Wang Z P, Xu Y Y, Tan D W, Li L, Wang D F, Wu W M. 2016. Sedimentary characteristics and mineralization model of high grade phosphorite in the Sinian Doushantuo Age of Kaiyang area,central Guizhou Province. Journal of Palaeogeography(Chinese Edition), 18(4): 581-594]
[18]	张亚冠, 杜远生, 陈国勇, 刘建中, 陈庆刚, 赵征, 王泽鹏, 邓超. 2019. 富磷矿三阶段动态成矿模式: 黔中开阳式高品位磷矿成矿机制. 古地理学报, 21(2): 351-368.
	[Zhang Y G, Du Y S, Chen G Y, Liu J Z, Chen Q G, Zhao Z, Wang Z P, Deng C. 2019. Three stages dynamic mineralization model of the phosphate rich deposits: Mineralization mechanism of the Kaiyang type high grade phosphorite in central Guizhou Province. Journal of Palaeogeography(Chinese Edition), 21(2): 351-368]
[19]	张亚冠, 杜远生, 刘建中, 王泽鹏, 邓超. 2020. 贵州震旦系陡山沱组磷块岩成磷作用及与新元古代末期氧化事件(NOE)的耦合. 古地理学报, 22(5): 893-912.
	[Zhang Y G. Du Y S, Liu J Z, Wang Z P, Deng C. 2020. Phosphogenesis of phosphorite from the Sinian Doushantuo Formantion in Guizhou Province and its coupling relation with the Neoproterzoic oxygenation event. Journal of Palaeogeography(Chinese Edition), 22(5): 893-912]
[20]	赵东旭. 1986. 震旦纪陡山沱组的碎屑磷块岩. 岩石学报, 2(3): 66-75,100.
	[Zhao D X. 1986. Intraclasic phosphorites of Doushantuo Formation in Sinian period. Acta Petrologica Sinica, 2(3): 66-75,100]
[21]	赵东旭. 1988. 磷块岩结核的显微结构和生成特点. 地质科学, 23(1): 57-67,99.
	[Zhao D X. 1988. Microstructures of concretionary phosphorites and their genetic characteristics. Chinese Journal of Geology, 23(1): 57-67,99]
[22]	朱士兴, 王砚耕. 1983. 关于开阳磷块岩矿床成因的探讨. 科学通报, 28(19): 1191-1194.
	[Zhu S X, Wang Y G. 1983. Discussion on the genesis of Kaiyang phosphorite deposit. Chinese Science Bulletin, 28(19): 1191-1194]
[23]	Abed A M, Abdalla R S. 1998. On the state of weathering of the Upper Cretaceous red phosphorites of Eshidiya,southern Jordan. Journal of African Earth Sciences, 27(1): 39-54.
[24]	Arning E T, Lückge A, Breuer L C, Gussone N, Birgel D, Peckmann J. 2009. Genesis of phosphorite crusts off Peru. Marine Geology, 262(1-4): 68-81.
[25]	Baioumy H M, Tada R, Gharaie M H M. 2007. Geochemistry of Late Cretaceous phosphorites in Egypt: implication for their genesis and diagenesis. Journal of African Earth Sciences, 49(1-2): 12-28.
[26]	Baturin G N. 1971. Stages of phosphorite formation on the ocean floor. Nature Physical Science, 232(29): 61-62.
[27]	Baturin G N. 1982. Phosphorites on the Sea Floor. Elsevier: 161-172.
[28]	Baturin G N. 1990. Geochemistry and origin of ferromanganese nodules. International Geology Review, 32(9): 916-929.
[29]	Benitez-Nelson C R, O’Neill L, Kolowith L C, Pellechia P, Thunell R. 2004. Phosphonates and particulate organic phosphorus cycling in an anoxic marine basin. Limnology and Oceanography, 49(5): 1593-1604.
[30]	Berner K R R. 1993. Authigenic apatite formation and burial in sediments from non-upwelling,continental margin environments. Geochimica et Cosmochimica Acta, 57(5): 991-1007.
[31]	Bertrand-Sarfati J, Flicoteaux R, Moussine-Pouchkine A, Ait Kaci A A. 1997. Lower Cambrian apatitic stromatolites and phospharenites related to the glacio-eustatic cratonic rebound(Sahara,Algeria). Journal of Sedimentary Research, 67(5): 957-974.
[32]	Chen L, Xiao S, Pang K, Zhou C, Yuan X. 2014. Cell differentiation and germ-soma separation in Ediacaran animal embryo-like fossils. Nature, 516(7530): 238-241.
[33]	Compton J, Mallinson D, Glenn C R, Filippelli G, Follmi K, Shields G, Zanin Y. 2000. Variations in the global phosphorus cycle. Society for Sedimentary Geology: 21-33.
[34]	Delaney M L. 1998. Phosphorus accumulation in marine sediments and the oceanic phosphorus cycle. Global Biogeochemical Cycles, 12(4): 563-572.
[35]	Filippelli G M. 2011. Phosphate rock formation and marine phosphorus geochemistry: the deep time perspective. Chemosphere, 84(6): 759-766.
[36]	Föllmi K B. 1996. The phosphorus cycle,phosphogenesis and marine phosphate-rich deposits. Earth-Science Reviews, 40(1): 55-124.
[37]	Föllmi K B, Garrison R E, Grimm K A. 1991. Stratification in phosphatic sediments: illustrations from the Neogene of Central California. In Einsele G,Ricken W,Seilacher A(eds),Cycles and events in stratigraphy. Heidelberg,Springer-Verlag: 492-507.
[38]	Gao Y P, Zhang X L, Zhang G J, Chen K F, Shen Y N. 2018. Ediacaran negative C-isotopic excursions associated with phosphogenic events: evidence from South China. Precambrian Research,307: 218-228.
[39]	Garrison R E, Kastner M. 1990. Phosphatic sediments and rocks recovered from the Peru margin during ODP Leg 112 Proccedings of the Ocean Drilling Program, Scientific Results,112: 1990.111-134.
[40]	Gleen C R, Föllmi K B, Riggs S R, Baturin G N, Grimm K A, Trappe J, Abed A M, Galli-Olivier C, Garrison R E, Ilyin A V, Jehl C, Rohrlich V, Sadaoah R M Y, Schidlowski M, Sheldon R E, Siegmund H. 1994. Phosphorus and phosphorites: sedimentology and environments of formation. Eclogae Geologicae Helvetiae, 87(3): 747-788.
[41]	Goldhammer T, Brüchert V, Ferdelman T G, Zabel M. 2010. Microbial sequestration of phosphorus in anoxic upwelling sediments. Nature Geoscience, 3(8): 557-561.
[42]	Gómez-Peral L E, Kaufman A J, Poiré D G. 2014. Paleoenvironmental implications of two phosphogenic events in Neoproterozoic sedimentary successions of the Tandilia System,Argentina. Precambrian Research,252: 88-106.
[43]	Krajewski K P, Leniak P M, Łᶏcka B, Zawidzki P. 2000. Origin of phosphatic stromatolites in the Upper Cretaceous condensed sequence of the Polish Jura Chain. Sedimentary Geology, 136(1): 89-112.
[44]	Nelson G J, Pufahl P K, Hiatt E E. 2010. Paleoceanographic constraints on Precambrian phosphorite accumulation,Baraga Group,Michigan,USA. Sedimentary Geology, 226(1-4): 9-21.
[45]	Planavsky N J, Grey K. 2008. Stromatolite branching in the Neoproterozoic of the centralian superbasin,Australia: an investigation into sedimentary and microbial control of stromatolite morphology. Geobiology, 6(1): 33-45.
[46]	Pufahl P K, Hiatt E E. 2012. Oxygenation of the Earth’s atmosphere-ocean system: a review of physical and chemical sedimentologic responses. Marine and Petroleum Geology, 32(1): 1-20.
[47]	Pufahl P K, Groat L A. 2017. Sedimentary and igneous phosphate deposits: formation and exploration: an invited paper. Economic Geology, 112(3): 483-516.
[48]	Pufahl P K, Grimm K A, Abed A M, Sadaqah R M Y. 2003. Upper Cretaceous(Campanian)phosphorites in Jordan: implications for the formation of a south Tethyan phosphorite giant. Sedimentary Geology, 161(3-4): 175-205.
[49]	Riggs S R. 1979. Petrology of the Tertiary phosphorite system of Florida. Economic Geology, 74(2): 195-220.
[50]	Ruttenberg K C. 1992. Development of a sequential extraction method for different forms of phosphorus in marine sediments. Limnology and Oceanography,37: 1460-1482.
[51]	Sánchez-Navas A, Martín-Algarra A. 2001. Genesis of apatite in phosphate stromatolites. European Journal of Mineralogy, 13(2): 361-376.
[52]	Schmitt M, Southgate P N. 1982. A phosphatic stromatolite(Ilicta cf. composita Sidorov)from the Middle Cambrian,northern Australia. Alcheringa, 6(3): 175-183.
[53]	She Z B, Strother P, McMahon G, Nittler L R, Wang J H, Zhang J H, Sang L K, Ma C Q, Papineau D. 2013. Terminal Proterozoic cyanobacterial blooms and phosphogenesis documented by the Doushantuo granular phosphorites I: in situ micro-analysis of textures and composition. Precambrian Research,235: 20-35.
[54]	She Z B, Strother P, Papineau D. 2014. Terminal Proterozoic cyanobacterial blooms and phosphogenesis documented by the Doushantuo granular phosphorites Ⅱ: microbial diversity and C isotopes. Precambrian Research,251: 62-79.
[55]	Soudry D. 1992. Primary bedded phosphorites in the Campanian Mishash Formation,Negev,southern Israel. Sedimentary Geology, 80(1-2): 77-88.
[56]	Southgate P N. 1980. Cambrian stromatolitic phosphorites from the Georgina Basin,Australia. Nature, 285(5764): 395-397.
[57]	Trappe J. 2001. A nomenclature system for granular phosphate rocks according to depositional texture. Sedimentary Geology, 145(1): 135-150.
[58]	Van Kauwenbergh S J. 2010. World phosphate rock reserves and resources. Muscle Shoals, IFDC:83-97.
[59]	Xiao S H, Knoll A H. 1999. Fossil preservation in the Neoproterozoic Doushantuo phosphorite lagerstatte,South China. Lethaia, 32(3): 219-240.
[60]	Xiao S H, Zhang Y, Knoll A H. 1998. Three-dimensional preservation of algae and animal embryos in a Neoproterozoic phosphorite. Nature,391: 553-558.
[61]	Zhang Y G, Pufahl P K, Du Y S, Chen G Y, Liu J Z, Chen Q G, Wang Z P, Yu W C. 2019. Economic phosphorite from the Ediacaran Doushantuo Formation,South China,and the Neoproterozoic-Cambrian phosphogenic event. Sedimentary Geology,388: 1-19.

异生磷酸盐颗粒(非生物席固定)						生物席固定
颗粒粒径<2 mm				10%以上颗粒粒径>2 mm		微生物席粘结磷灰石沉积或作为磷灰石沉积基底
泥质基质 (白云质、磷质微晶基质)		非泥质基质 (粒间胶结物或孔隙)		泥质基质 (白云质、磷质泥晶基质)	非泥质基质 (粒间胶结物或孔隙)
颗粒含量<10%	颗粒含量>10%	颗粒支撑
基质支撑		颗粒支撑
泥状磷块岩/ 微晶磷块岩	粒泥磷块岩	泥粒磷块岩	粒状磷块岩	漂砾磷块岩	粗砾磷块岩	生物粘结磷块岩

异生磷酸盐颗粒(非生物席固定)						生物席固定
颗粒粒径<2 mm				10%以上颗粒粒径>2 mm		微生物席粘结磷灰石沉积或作为磷灰石沉积基底
泥质基质 (白云质、磷质微晶基质)		非泥质基质 (粒间胶结物或孔隙)		泥质基质 (白云质、磷质泥晶基质)	非泥质基质 (粒间胶结物或孔隙)
颗粒含量<10%	颗粒含量>10%	颗粒支撑
基质支撑		颗粒支撑
泥状磷块岩/ 微晶磷块岩	粒泥磷块岩	泥粒磷块岩	粒状磷块岩	漂砾磷块岩	粗砾磷块岩	生物粘结磷块岩

沉积类型	岩相	岩石学特征	沉积构造	沉积环境
碎屑岩相	厚层含砾石英砂岩相(F1)	灰绿色,由大小不一、磨圆较好的砾石和粗砂组成	厚层,砾石可见叠瓦状组构	无障壁海滩前滨—临滨
	厚层中细粒石英砂岩相(F2)	灰绿色,由分选较好、磨圆中等的中细粒石英组成,含海绿石、长石、粘土矿物等	中—厚层,层内可见大型板状交错层理、平行层理或浪成交错层理	无障壁海滩前滨—上临滨
	中薄层粉砂—泥质岩相(F3)	灰绿色—灰黑色,粉砂—黏土质,粉砂为石英,分选、磨圆中等,偶含海绿石	可见小型浪成交错层理、水平层理或脉状层理、波状层理	下临滨—远滨带
碳酸盐岩相	厚层含锰白云岩相(F4)	灰白色,由细—微晶白云石组成,可见重晶石扇	厚层,发育席状裂隙、帐篷构造和瘤状突起	滨岸潮坪朝下带
	中厚层鲕粒白云岩相(F5)	灰色,中厚层,主要由白云石组成,鲕粒发育	可见平行层理和交错层理	潮下带
	中厚层微晶白云岩相(F6)	灰—灰白色,微晶白云石为主,常见玉髓,硅化	中—厚层,孔洞较普遍	近岸浅海环境,受准同生暴露、淋滤影响
	含磷白云岩相(F7)	灰白色—白色,微晶—粗晶白云岩,硅化作用发育	块状、含大量溶蚀角砾和溶蚀孔洞	极浅水海岸暴露环境
磷块岩相	(含碳)泥晶磷块岩相(F8)	灰黑色—黑色,主要矿物成分为隐晶到微晶质磷灰石,含有机质成分,夹泥页岩、泥晶白云岩及硅质岩	薄层,含水平纹层和硅质岩、泥晶白云岩透镜体等	远滨(浅海)相
	块状砾屑磷块岩相(F9)	灰色,含大量磷质砾屑及少量砂屑、白云质砾石	块状,砾石可见叠瓦状或菊花状排布	滨岸高能水体环境,或风暴流影响
	中厚层砂屑磷块岩相(F10)	灰—深灰色,中—粗粒,磷质内碎屑、鲕粒、生物颗粒或球粒为主	中—厚层,可见大型板状交错层理、平行层理或浪成交错层理	无障壁海滩,后滨—前滨相、上临滨带
	纹层状细—粉屑磷块岩相(F11)	灰—深灰色,由磷质细—粉屑组成,夹泥晶磷质或白云质细纹层或条带	薄层,可见水平纹层、小型浪成交错层理	下临滨相—远滨环境
	粘结磷块岩相(F12)	灰—灰白色,含叠层石、藻纹层、藻球粒等	块状,微生物纹层呈水平状或宆形柱状状	潮坪或较局限的浅水低水动能海域
	微生物磷块岩相(F13)	具微生物胚胎或球粒,化石成分为主要磷酸盐	中厚层状,均质层理或水平层理	下临滨或远滨带
	条带状砂屑磷块岩相(F14)	灰—灰白色,由磷质颗粒条带和细晶白云石条带组成	白云石条带和磷质颗粒条带呈互层状产出	滨岸浅水环境,白云石条带为蒸发作用有关
	渣状—土状半土状磷块岩(F15)	灰黄色到灰黑色,由疏松、破碎的磷块岩组成	块状构造	原生磷块岩暴露、淋滤形成

沉积类型	岩相	岩石学特征	沉积构造	沉积环境
碎屑岩相	厚层含砾石英砂岩相(F1)	灰绿色,由大小不一、磨圆较好的砾石和粗砂组成	厚层,砾石可见叠瓦状组构	无障壁海滩前滨—临滨
	厚层中细粒石英砂岩相(F2)	灰绿色,由分选较好、磨圆中等的中细粒石英组成,含海绿石、长石、粘土矿物等	中—厚层,层内可见大型板状交错层理、平行层理或浪成交错层理	无障壁海滩前滨—上临滨
	中薄层粉砂—泥质岩相(F3)	灰绿色—灰黑色,粉砂—黏土质,粉砂为石英,分选、磨圆中等,偶含海绿石	可见小型浪成交错层理、水平层理或脉状层理、波状层理	下临滨—远滨带
碳酸盐岩相	厚层含锰白云岩相(F4)	灰白色,由细—微晶白云石组成,可见重晶石扇	厚层,发育席状裂隙、帐篷构造和瘤状突起	滨岸潮坪朝下带
	中厚层鲕粒白云岩相(F5)	灰色,中厚层,主要由白云石组成,鲕粒发育	可见平行层理和交错层理	潮下带
	中厚层微晶白云岩相(F6)	灰—灰白色,微晶白云石为主,常见玉髓,硅化	中—厚层,孔洞较普遍	近岸浅海环境,受准同生暴露、淋滤影响
	含磷白云岩相(F7)	灰白色—白色,微晶—粗晶白云岩,硅化作用发育	块状、含大量溶蚀角砾和溶蚀孔洞	极浅水海岸暴露环境
磷块岩相	(含碳)泥晶磷块岩相(F8)	灰黑色—黑色,主要矿物成分为隐晶到微晶质磷灰石,含有机质成分,夹泥页岩、泥晶白云岩及硅质岩	薄层,含水平纹层和硅质岩、泥晶白云岩透镜体等	远滨(浅海)相
	块状砾屑磷块岩相(F9)	灰色,含大量磷质砾屑及少量砂屑、白云质砾石	块状,砾石可见叠瓦状或菊花状排布	滨岸高能水体环境,或风暴流影响
	中厚层砂屑磷块岩相(F10)	灰—深灰色,中—粗粒,磷质内碎屑、鲕粒、生物颗粒或球粒为主	中—厚层,可见大型板状交错层理、平行层理或浪成交错层理	无障壁海滩,后滨—前滨相、上临滨带
	纹层状细—粉屑磷块岩相(F11)	灰—深灰色,由磷质细—粉屑组成,夹泥晶磷质或白云质细纹层或条带	薄层,可见水平纹层、小型浪成交错层理	下临滨相—远滨环境
	粘结磷块岩相(F12)	灰—灰白色,含叠层石、藻纹层、藻球粒等	块状,微生物纹层呈水平状或宆形柱状状	潮坪或较局限的浅水低水动能海域
	微生物磷块岩相(F13)	具微生物胚胎或球粒,化石成分为主要磷酸盐	中厚层状,均质层理或水平层理	下临滨或远滨带
	条带状砂屑磷块岩相(F14)	灰—灰白色,由磷质颗粒条带和细晶白云石条带组成	白云石条带和磷质颗粒条带呈互层状产出	滨岸浅水环境,白云石条带为蒸发作用有关
	渣状—土状半土状磷块岩(F15)	灰黄色到灰黑色,由疏松、破碎的磷块岩组成	块状构造	原生磷块岩暴露、淋滤形成
